CHAM BATTERY TECHNOLOGY CO., LTD ® (CHAM BATTERY) was established in 2003 with an initial investment of well over 15million US$. With our manufacturing facility of around 10,000 square meters and production capabilities in excess of 80.000 cells per day, we can fulfill all your requirements.

 As one of the leading Lithium Ion battery manufacturers in China, CHAM BATTERY has been fully dedicated towards the development and production of the best Cylindrical Li-ion batteries from the day founded. Our highly qualified R&D team, with branches in both ShenZhen and BeiJing, is leaded by Mr. CHENLIQUAN, academician of the Chinese academy of engineering, who is a pioneer and world renowned expert in the research of Li-ion batteries. Besides offering state-of-the-art Li-ion batteries, we design and produce many of our own production equipment to keep up with our high standards of engineering and cost targets.

 With the principle of “Advanced Technology, Satisfying Service and Excellent Performance”, CHAM BATTERY is aiming to provide 100% satisfying products and services to our customers. All factory operations are ISO9001:2000 Certified, and our batteries are UL-listed, CE-marked and RoHs compliant.

Contacting CHAM BATTERY for your current or next generation of products will therefore undoubtedly result in a long lasting and successful cooperation for all your power requirements.

Select Language

English   Chinese

Newflash
Packs -



Cells -

Since 1990, lithium ion battery gets rapid development for its light weight, high performance and environmentally-friendly characteristics. Now it's widely used in notebook ,digital portable products, power tools, medical device, military and HEV etc.


Energy cells
our high energy cells can provide the long lasting energy for the portable equipment etc.

 the max capacity  18650 is 2.6Ah .General feature

•          High energy density
•          Light weight
•          Over 500 discharge cycles
•          Three safety protections
•          No memory effect
•          Capacity varies from 0.7Ah  to 2.6Ah

 Power Cells

Our high power cells which can be discharged with big current till to 25C are widely used in Power tools and related applications.

General feature

•          High energy density
•          Light weight
•          Over 500 big current of 10C discharge cycles
•          No memory effect
•          High rate discharge  at 25C peak discharge

                                                                              Energy Cells List

Product Type

Nominal        Voltage

  (V)

Nominal        Capacity(mAh)

 Dimensionslt(mm)

 Impedence  (mΩ)

 Weightlt(g)

Diameter     (max)

height    (max)

CMICR18650F

3.7

2600

18.4

65.3

<60

46.5±1

CMICR18650F

3.7

2400

18.4

65.3

<60

45.0±1

CMICR18650F

3.7

2200

18.3

65.0

<60

43.5±1

CMICR18650F

3.7

2000

18.3

65.0

<60

42.5±1

CMICR18500F

3.7

1400

18.3

49.1

<70

32.5±1

CMICR17670F

3.7

1600

16.8

67.0

<50

39.5±1

CMICR17500F

3.7

1150

16.8

49.0

<70

27.5±1

CMICR14500F

3.7

750

14.1

49.8

<60

19.0±1

CMICR14430F

3.7

700

14.1

42.3

<60

16±0.5

CMIFR18650F

3.2

1600

18.3

65.0

<60

39.0±1

CMIFR22650F

3.2

2300

22.3

65.0

<60

58.5±1





                                                 Power Cells List



Product Type

Nominal        Voltage    (V)

Nominal        Capacity(mAh)

Rate performance

 Impedence  (mΩ)

 Weightlt(g)

Max constant
discharge current(A)

Max Pulse
discharge current(A)

CMICR18650F3S

3.6

1300

15

32

<20

42.0±1

CMICR18650F3T

3.6

1300

15

26

<25

44.0±1

CMICR18650F3B

3.6

1300

13

20

<25

42.0±1

CMICR18650F37

3.6

1300

10

20

<35

40.0±1

CMICR18650F36

3.7

1300

8

15

<35

43.0±2

CMICR18650F3E

3.8

1000

6

15

<35

40.0±3

CMICR18650F6

3.6

1600

13

24

<30

44.0±1

CMIFR18650F3

3.2

1200

12

24

<30

39.0±1
