Main Specifications
-
Related Products
Main Product Parameters
-
7660
-
7645
-
7630-A
-
7630-C
-
7630-D
-
-
Cell Specification
LFP
-
Dimensions
460*260*170mm
-
Weight
33kg
-
Rated Voltage
76.8V
-
Rated Capacity
60Ah
-
Charging Limit Voltage
87.6V
-
Discharging Cut-off Voltage
60V
-
Max Charging Current
30A
-
Max Discharging Current
100A
-
Charging Operating Temperature
0℃~55℃
-
Discharging Operating Temperature
-20℃~60℃
-
Protection Class
IP 67
-
-
-
Cell Specification
LFP
-
Dimensions
460*225*170mm
-
Weight
27kg
-
Rated Voltage
76.8V
-
Rated Capacity
45Ah
-
Charging Limit Voltage
87.6V
-
Discharging Cut-off Voltage
60V
-
Max Charging Current
22.5A
-
Max Discharging Current
80A
-
Charging Operating Temperature
0℃~55℃
-
Discharging Operating Temperature
-20℃~60℃
-
Protection Class
IP 67
-
-
-
Cell Specification
LFP
-
Dimensions
338*225*170mm
-
Weight
18.5kg
-
Rated Voltage
76.8V
-
Rated Capacity
30Ah
-
Charging Limit Voltage
87.6V
-
Discharging Cut-off Voltage
60V
-
Max Charging Current
15A
-
Max Discharging Current
60A
-
Charging Operating Temperature
0℃~55℃
-
Discharging Operating Temperature
-20℃~60℃
-
Protection Class
IP 67
-
-
-
Cell Specification
LFP
-
Dimensions
390*180*170mm
-
Weight
18.5kg
-
Rated Voltage
76.8V
-
Rated Capacity
30Ah
-
Charging Limit Voltage
87.6V
-
Discharging Cut-off Voltage
60V
-
Max Charging Current
15A
-
Max Discharging Current
60A
-
Charging Operating Temperature
0℃~55℃
-
Discharging Operating Temperature
-20℃~60℃
-
Protection Class
IP 67
-
-
-
Cell Specification
LFP
-
Dimensions
400*160*170mm
-
Weight
18.5kg
-
Rated Voltage
76.8V
-
Rated Capacity
30Ah
-
Charging Limit Voltage
87.6V
-
Discharging Cut-off Voltage
60V
-
Max Charging Current
15A
-
Max Discharging Current
60A
-
Charging Operating Temperature
0℃~55℃
-
Discharging Operating Temperature
-20℃~60℃
-
Protection Class
IP 67
-
